EVO TRA T
TEMPERATURE RTD PROBE WITH INTEGRATED M12 CONNECTOR AND 4 ÷ 20mA OUTPUT
High accuracy and set up by software. The trasmitter and the probe are integrated in one device

Technical data




Absolute accuracy <=0.1% of span (more than 0.3°C)
General specifications Supply Voltage: 8 ÷ 35Vdc
Internal consumption: 25mW ÷ 0.8W
Signal/noise ratio: Min. 60dB
Input signal dynamics: 19 bit Output Signal dynamics: 16 bit
Temperature coefficient <=0.01% of span / °C (more than 0.01°C / °C)
Working environment specifications Temperature: -40°C to +85°C
Humidity: 0/100% RH
Tightness IP67
Observed authority Requirements - EMC 89/336/EEC - Emission EN 50 081-1 - EN 50 081-2, Immunity EN 50 082-2, EN 50 082-1
Effect of supply voltage variation =0.005% of span / VDC
EMC immunity influence <=0.5% of span
Input RTD Pt100 srew in probe for direct immersion with 1/8' GAS process connection. Available immersion lenght 13 or 24 mm.
Temperature measurement range: -50°C ÷ + 120°C
Output Signal Range: 4 ÷ 20 mA
Updating time: 135 ms
Output connection M12x1 male in accordance with VDE0627
Sensor error detection Programmable: 3.5...23 mA
NAMUR NE43 Upscale: 23 mA
NAMUR NE43 - Downscale: 3.5 mA
Process connection 1/8" GAS thread, according to UNI-ISO 228
