| This unit can power a network of up to 32
Evoser devices
|
|
|
|
| Technical data |
|
|
|
|
|
|
| Working environment |
Temperature:0°C
÷ 50ºC
Humidity:10% ÷ 85% non condensing |
| Dimensions (mm) |
60 x 110 x 100 |
| Type of power supply |
Switching |
| Mains power |
90 ÷ 264 V AC,
frequency 47÷63 Hz |
| Output voltage |
24 V DC ±10% |
| Nominal current |
2,5 A
continuous service |
| Ripple with nominal
Io |
150 mV pp |
| Over voltage thresold |
27,6÷30 V DC |
| Efficiency |
Min. 75% |
| Maintenence at switch
off |
16mSec. |
| Others features |
Isolated output
Short
circuit protection on output
Equipped for installation to DIN bar
Certificate
UL-CSA (file ref. E159228) |
|
|
|
ITALCOPPIE
