EVO STOP T
INTEGRATED ELECTRONIC TEMPERATURE SWITCH WITH PROCESS CONNECTION



Technical data




Environment range Temperature: -25°C / +80°C
Humidity: 0/100% RH
Sensing element Pt100 probe: range -100,0 ÷ 500,0 °C
Power supply 12-30 V DC 0,7W max.
Output signal PNP transistor (NPN upon request)
Updating frequency 1 reading per second
Driving current 100mA max with short circuit protection
Output connection M12x1 male to DIN-VDE0627 degree of protection IP67
Total measurement error With ambient temperature between -10°C e 50°C: ±0,5°C
Resolution 0,1°C
Parameters programmation By EVOSTOPSET kit
Body material AISI 316 S.S.
Waterproof to IP 67
Process connection 1/8" GAS thread, according to UNI-ISO 228
